Bag Load Push
Application:
Bag Load Push is designed for heavy use under harsh conditions. Non-slipsheeted goods can be pushed into position with brute force against other loads in order to create straight positioning and to optimize space inside sea containers.
Features:
- High strength steel structure design, meet user efficient continuous operation.
- Meet the job in different working conditions.
- Reasonable design, good field of vision
Specification:
| Type | Capacity @Load Center /kg@mm |
Mounting Class |
Width of Faceplate /mm |
Height of Faceplate /mm |
Sideshit /mm |
Stroke /mm |
Round Diamensions /mm |
Number of Round /Bars |
Weight /kg |
style=”text-align: center;”>Effective Thickness /mm |
| PLB20D-001A | 1600@600 | II | 1000 | 1000 | null | 1180 | Φ55×1200 | 6 | 550 | 241 |
| PLB30D-002B | 2500@600 | III | 1000 | 1000 | null | 1180 | Φ55×1200 | 6 | 590 | 241 |
| PLS30D-003B | 2500@600 | III | 1000 | 1000 | +/-100 | 1280 | Φ55×1300 | 6 | 650 | 241 |
| PLS30D-004B | 2500@600 | III | 1000 | 1000 | null | 1180 | Φ55×1200 | 6 | 620 | 241 |
| PLS30D-005B | 2500@600 | III | 1200 | 1200 | +/-100 | 1280 | Φ55×1300 | 6 | 680 | 241 |
| PLS30D-006B | 2500@600 | III | 1200 | 1200 | null | 1180 | Φ55×1200 | 6 | 650 | 241 |
| PLS30D-007B | 2500@600 | III | 1200 | 1200 | +/-100 | 1380 | Φ55×1400 | 6 | 710 | 241 |
Note:
- Obtain the actual capacity of the forklift and attachments from the forklift manufacturer,
- One/Two sets additional oil circuit required on forklift
- Please contact the sales from Huamai.
Hydraulic Flow & Pressure:
| Model | Min.Hydraulic Flow(L/min) | Rec. Hydraulic Flow(L/min) | Max.Hydraulic Flow(L/min) | Min. Hydraulic Pressure(Bar) | Max. Hydraulic Pressure(Bar) |
| PLB20D | 20 | 40 | 60 | 35 | 160 |
| PLB30D | 20 | 40 | 60 | 35 | 160 |
Options:
- Fork/Round Bar
- Extended and lengthen push board
